HID Corporate 1000 35-Bit Compatibility Guide: Cards, Fobs & Facility Codes

If your organization runs on HID Corporate 1000, you already know it isn't an off-the-shelf credential. Corporate 1000 is a customer-specific, HID-managed 35-bit format, which means the cards, fobs, and tags your readers accept are tied to a facility code and card-number range assigned to your program. When you need to add credentials, replace lost badges, or bring on a new site, the credentials have to match that exact format — a generic 26-bit prox card will simply be rejected at the reader.

This guide explains how the Corporate 1000 35-bit format is structured, how it differs from the standard 26-bit format, why HID keeps it customer-specific, and how to order compatible cards and fobs that carry your facility code and card numbers correctly. AuthorizID supplies credentials compatible with the Corporate 1000 format, so you can source matching cards and fobs without paying a premium for every reorder.

Free samples are available so you can test compatibility before you buy. Request a free Corporate 1000 sample credential to test on your reader



What Is HID Corporate 1000?

Corporate 1000 (often written C1000) is a managed credential program from HID. Instead of using a shared, publicly documented card format, a Corporate 1000 customer is assigned a unique format that only their organization uses. HID tracks the facility codes and card numbers issued under that program so no two credentials collide, which is a large part of why enterprises adopt it.

The practical benefits for a big deployment are straightforward:

• A huge, exclusive card-number pool so a large enterprise won't run out of unique credentials or accidentally reuse a number that's already active elsewhere.
• Format exclusivity, meaning a random prox card bought online won't authenticate on your readers — only credentials programmed to your Corporate 1000 format will work.
• Centralized number management, so multi-building and multi-region organizations can keep one clean credential scheme instead of juggling overlapping 26-bit facility codes.

Corporate 1000 is most commonly deployed as the 35-bit format covered in this guide. HID also offers a higher-capacity 48-bit Corporate 1000 variant for very large programs, but the 35-bit format is the one most buyers are searching for and reordering against.



The Corporate 1000 35-Bit Format Explained

A Wiegand credential is really just a string of bits: some carry the facility (or company) code, some carry the card number, and a few are parity bits used to check the read for errors. The HID 35-bit format lays those 35 bits out like this:

• Bit 1 — leading parity bit.
• Bit 2 — even parity bit.
• Bits 3–14 — the facility code (also called the company or customer code), 12 bits wide.
• Bits 15–34 — the card number, 20 bits wide.
• Bit 35 — trailing parity bit.

Those field widths are what give Corporate 1000 its capacity. A 12-bit facility code allows 4,096 possible facility codes (0–4,095), and a 20-bit card number allows 1,048,575 card numbers per facility code — over a million credentials. That's the room a national enterprise needs.



Why the facility code matters so much

The facility code is the number that tells your access panel "this credential belongs to our organization." On Corporate 1000, that facility code is assigned to your program and is part of what makes the format customer-specific. When you order replacement or additional credentials, they must be encoded with your facility code and with card numbers that fall in your assigned, un-issued range. Order the wrong facility code and the cards read as invalid; order card numbers that overlap existing badges and you create duplicate-credential conflicts at the door.

This is the single most important thing to get right on a C1000 reorder, and it's why "what's your facility code and card-number range?" is the first question any credential supplier should ask.



Corporate 1000 35-Bit vs. Standard 26-Bit H10301

The easiest way to understand Corporate 1000 is to compare it against the format it was designed to outgrow: the open 26-bit H10301 standard that most access control systems support out of the box.

Here's how the two formats stack up:

• 26-bit H10301 structure: 1 leading even-parity bit, an 8-bit facility code (bits 2–9), a 16-bit card number (bits 10–25), and 1 trailing odd-parity bit.
• Corporate 1000 35-bit structure: parity bits plus a 12-bit facility code (bits 3–14) and a 20-bit card number (bits 15–34).

And here's why that difference matters in the real world:

• Facility code range. 26-bit gives you only 256 facility codes (0–255). Corporate 1000 gives you 4,096. With 26-bit, large integrators quickly run into facility-code collisions between customers — two different buildings can end up with the same facility code, which is a security problem.
• Card-number capacity. 26-bit tops out at 65,535 card numbers per facility code. Corporate 1000's 20-bit field holds over a million. A single large employer can blow past 65,535 badges over the life of a system.
• Open vs. managed. 26-bit H10301 is an open, published format anyone can order. Corporate 1000 is a managed format — HID controls the format assignment and tracks the numbers, so credentials aren't freely duplicable by just anyone with a card printer.

In short: 26-bit is the universal default that works everywhere but offers a small, shared number space. Corporate 1000 35-bit trades that universality for a large, exclusive number space and tighter control — which is exactly what an enterprise locked into a managed HID program wants. If your system runs standard prox instead, our 26-bit H10301 credentials are the right fit; if you're on C1000, you need format-matched credentials from the Corporate 1000 35-bit collection.



Are My Readers and Panels Compatible?

Corporate 1000 35-bit is a Wiegand format, so it works with the broad ecosystem of 125 kHz proximity readers and controllers that can read a 35-bit Wiegand string — provided the panel is configured to accept that bit length and your facility code. A few points worth confirming:

• HID proximity readers that were part of your original Corporate 1000 rollout are already set up for the format. Adding matching credentials is the normal case.
• Access control panels/controllers (from the major head-end brands) generally accept custom Wiegand bit lengths, but the panel has to be told to read 35-bit and to trust your facility code. If a card reads as "invalid format" or gives no read at all, the panel's format definition is the first thing to check.
• Multi-technology readers can often be ordered or configured to read Corporate 1000 alongside other formats, which is useful during a migration.

Because compatibility ultimately depends on how your specific panel is programmed, the reliable way to confirm a credential works is to test one on your own reader before placing a full order — more on that below.



Credential Form Factors for Corporate 1000 35-Bit

Once a credential is encoded to your Corporate 1000 facility code and card number, the physical form factor is your choice. The same 35-bit data can live in whatever shape suits how people move through your building:

• Printable CR80 cards — standard credit-card-size PVC you can print with photos, names, and logos on an ID printer. The default for employee badges. See printable CR80 cards.
• Clamshell cards — thicker, rugged cards ideal for slot punches and lanyards where you won't direct-print. See clamshell cards.
• Key fobs — compact fobs for contractors, deliveries, or anyone who'd rather carry a keyring credential than a badge. See access key fobs.
• Adhesive tags — small stick-on prox tags for converting an existing card, phone case, or device into a credential.
• Wristbands — hands-free credentials for gyms, pools, aquatics, and high-turnover access environments.

The key point is that the form factor doesn't change the format: whether it's a card, fob, tag, or wristband, it must be encoded to your Corporate 1000 35-bit facility code and an available card number to work on your readers.



How to Order Corporate 1000 35-Bit Credentials

Ordering C1000 credentials is different from grabbing generic 26-bit prox cards, because the encoding has to match your managed program exactly. To place an accurate order, have this information ready:

• Your facility code — the code assigned to your Corporate 1000 program.
• The card-number range you want printed — specifically, a block of numbers that haven't already been issued, so you don't create duplicates.
• The form factor and quantity — cards, fobs, tags, or wristbands.

If you're not sure of your facility code or which card numbers are still available, check with whoever manages your access control system or your original integrator before ordering. Encoding a batch to the wrong facility code or an overlapping number range is the most common — and most preventable — mistake on a Corporate 1000 reorder.

AuthorizID sells credentials compatible with the Corporate 1000 format and ships nationwide with U.S.-based technical support, so once you have your facility code and number range, matching your existing badges is straightforward. If you want to confirm your details before a large run, a single sample credential is the safest first step.



Which Corporate 1000 Option Should You Choose?

To recap the decision:

• Choose Corporate 1000 35-bit if your organization is already enrolled in the C1000 program and your readers expect that format — this is a compatibility requirement, not a preference.
• Match your existing facility code and an unused card-number range on every reorder, regardless of form factor.
• Pick the form factor per use case: printable CR80 for employee badges, clamshell for rugged lanyard use, fobs for contractors, tags for device conversion, wristbands for hands-free access.
• If you're not on Corporate 1000 at all, and your panel reads open prox, standard 26-bit H10301 is the simpler, universal choice — but it won't work on a reader locked to your C1000 format, and vice versa.



Test Corporate 1000 Compatibility Before You Order

The surest way to confirm a credential works with your system is to test one on your own reader. A single Corporate 1000 35-bit sample encoded to your facility code lets you verify the read at the door — and catch any panel-configuration issues — before you commit to a full production run of cards or fobs.

Get in touch to claim a free Corporate 1000 35-bit sample credential
